Model ID | Model Name | First Hour Rating G.P.H. | Recovery in G.P.H. @ 90 | Tank Height | Height to Water Conn. | Diameter | Approx. Ship Wt. |
---|---|---|---|---|---|---|---|
965 | 82V30-2 | 48 | 21 | 45.75 | 45.75 | 17.75 | 80 |
966 | 82V40-2 | 53 | 21 | 46.5 | 46.5 | 19.75 | 95 |
967 | 82V52-2 | 67 | 21 | 57 | 57 | 19 | 107 |
968 | 82V66-2 | 71 | 21 | 58.5 | 58.5 | 21 | 150 |
969 | 82V80-2 | 88 | 21 | 59 | 59 | 23 | 177 |
970 | 82V120-2 | 99 | 21 | 62.5 | 62.5 | 28.25 | 324 |
971 | 82SV20-2 | - | 21 | 31.5 | 31.5 | 17 | 62 |
972 | 82SV30-2 | 42 | 21 | 30 | 30 | 22.25 | 83 |
973 | 82SV40-2 | 45 | 21 | 31.5 | 31.5 | 23 | 108 |
974 | 82SV50-2 | 55 | 21 | 32 | 32 | 26.25 | 149 |
1924 | 83VR40-2 | 56 | 21 | 46.75 | 46.75 | 22.25 | 104 |
1925 | 83VR52-2 | 67 | 21 | 57 | 57 | 22.25 | 123 |
1926 | 83VR66-2 | 71 | 21 | 58.75 | 58.75 | 23 | 160 |
1927 | 83VR80-2 | 88 | 21 | 59 | 59 | 24.5 | 181 |
1928 | 83MVR52-2 | 62 | 21 | 46 | 46 | 21.75 | 117 |
1929 | 82VH40-2 | 57 | 21 | 59.25 | 59.25 | 17.75 | 96 |
1930 | 81SVB30-2 | 42 | 21 | 30 | 30 | 19.75 | 90 |
1931 | 82MV52-2 | 62 | 21 | 46 | 46 | 21.75 | 117 |
1932 | 82MV30-2 | 44 | 21 | 36 | 36 | 19.75 | 80 |
